DESCRIPTION

Basic Info.

Model NO.	LM-PG01800A
Warranty	5 Years
Housing Material	Alum. Alloy
Life	50000h
LED Chips	Samsung
Certification	CE, RoHS
Chip Brand	Samsung Lm301b/Taiwan
PF	>0.9
High CRI	Ra>85
Long Life Span	50000 Hours
Transport Package	21
Specification	1150*1110*100MM
Trademark	lumin lighting
Origin	China
HS Code	9405100000
Production Capacity	20000PCS/ Month

Product Description

The Spydrx LED Grow light evolved from the traditional plant light. Based on the full-spectrum principle of sunlight, G2 adopts the latest LED production technology to achieve the same lighting effect. While saving power and protecting the environment, it greatly improves the plant's growth efficiency.
Features
(1) Spydrx design, adjustable bars and easy maintenance
(2) High quality LED chips: Samsung lm301b chips
(3) full spectrum: 3000K+5000K+660nm. Other spectrum canbe customized, UV, IR, 450nm, 660nm peak all are available (4) Daisy Chained dimming: By wifi/touch screen or Knob dimmer
(4) Long lifespan,low optical decay, more than 50,000h lifespan
(5) Various power for choosing

No.	LM-PG01480	LM-PG01640	LM-PG01800	LM-PG011000
Light sourse:	Samsung LM301B/Taiwan Chips	Samsung LM301B/Taiwan Chips	Samsung LM301B	Samsung LM301B
Spectrum:	Full spectrum	Full spectrum	Full spectrum	Full spectrum
PPF:	750umol/s-840umol/s	1200umol/s-1344umol/s	1625umol/s-1820umol/s	2500umol/s-2800umol/s
PPF efficacy:	2.5umol/J-2.8umol/J	2.5umol/J-2.8umol/J	2.5umol/J-2.8umol/J	2.5umol/J-2.8umol/J
Input power:	480W±5%	640W±5%	800W±5%	1000W±5%
Input voltage:	100-277V	100-277V	100-277V	100-277V
Fixture dimensions:	1050*780*100mm	1050*1030*100mm	1050*1300*100mm	1050*1300*100mm
Gross weight:	21kg	24kg	27KG	28kg
Mounting height:	≥6inch	≥6inch	≥6inch	≥6inch
Lifespan:	50000 hours	50000hours	50000hours	50000hours
Warranty:	5 years	5 years	5 years	5 years
Certificate:	CE,RoHS	CE, ROHS	CE, ROHS	CE, ROHS

Application
Plant factory, Greenhouse, Farms, etc.
Parameter
Benefits

1. High performance aluminum alloy housing, Fast heat dissipation, Uniform illumination , life span up to 50000 hours.
2. External aluminum alloy no flicker power supply
3. Better heat dissipation than plastic power driver
4. Healthier than stroboscopics which could cause brain tumor.
5. It has full voltage, high stability, high precision, high transformation efficiency, short circuit protection function.

The use of aluminous shell for better heat dispersion and longer life time.
6. We have rich experience in OEM/ODM.
7. The ratio of full spectrum : scientific-proven ratio of full light spectrum which is suitable for different stages

(with different height to plant) of plant growth and enhanceing photosynthesis.

Pictures of the Product

Samsung Chips + Osram 660nm Chips + Inventronics Driver
